Les HPE Aruba Networking 630 Series Campus Access Points sont conçus pour tirer parti de la bande 6 GHz en utilisant trois radios pour une couverture tri-bande complète. Avec la bande des 6 GHz, la capacité sans fil est plus que doublée, ce qui permet aux entreprises de répondre à leurs besoins actuels et de prévoir la croissance future. Les points d'accès Wi-Fi 6E permettent aux pays de tirer parti du Wi-Fi 6E, après son approbation dans le pays, via une notification automatisée et un déploiement facile des tables réglementaires de la bande 6 GHz. La série 630 offre un taux d'agrégation des données maximum de 3,9 Gbit/s pour un débit plus élevé et des vitesses plus rapides, pour une utilisation intérieure fixe à faible consommation. Avec jusqu'à sept canaux 160 MHz, les AP 630 maximisent la performance pour les applications à faible latence, gourmandes en bande passante. La fonction de filtrage ultra tri-bande supprime les interférences entre les bandes 5 GHz et 6 GHz et évite les écarts dans la couverture des canaux. Pour assurer une haute disponibilité, la série 630 inclut un basculement à deux ports sans heurt pour le réseau Ethernet et l'alimentation.

HPE Aruba Networking AP-635 (US) Tri Radio 2x2 802.11ax Wi-Fi 6E Internal Antennas TAA Campus AP

HPE Aruba Networking 630 Series Campus Access Points are designed to take advantage of the 6 GHz band using three radios for comprehensive tri-band coverage. With 6 GHz, wireless capacity is more than doubled allowing enterprises to meet the today needs and plan for future growth. The Wi-Fi 6E APs allow countries to take advantage of Wi-Fi 6E once it is approved in country through automated notification and easy deployment of 6 GHz regulatory tables. The 630 Series delivers a maximum aggregate 3.9 Gbps data rate for higher throughput and faster speeds for fixed low power indoor use. With up to seven 160 MHz channels, the 630 APs maximizes performance for low-latency, bandwidth-hungry applications. The ultra tri-band filtering eliminates interference between 5 GHz and 6 GHz and prevents gaps in channel coverage. To ensure high availability, the 630 Series includes dual port hitless failover for ethernet and power.

Three radios to extend the benefits of Wi-Fi 6E to the 6 GHz band –unlocking up to 1200 MHz of spectrum.

Wider channels and less interference to deliver faster speeds for ow-latency, bandwidth-hungry applications like high-definition video and augmented reality/virtual reality.

Unique filtering capabilities to mitigates gaps in coverage and help minimize interference between the 5 GHz and 6 GHz bands.

High availability with hitless failover for Ethernet and power to help ensure business continuity.

Automated notification and easy deployment of 6 GHz regulatory tables to allow countries to take advantage of Wi-Fi 6E once it is approved in country.

More Capacity and Wider Channels with Wi-Fi 6E

• The HPE Aruba Networking 630 Series Campus Access Points deliver a maximum aggregate 3.9 Gbps data rate for higher throughput and faster speeds.
• With up to seven 160 MHz channels, the APs help maximize performance for low-latency, bandwidth-hungry applications.
• It is designed for low power indoor environments (LPI).

Less Interference and Fewer Coverage Gaps

• The HPE Aruba Networking 630 Series Campus Access Points provide comprehensive tri-band coverage using three radios.
• The HPE Aruba Networking unique ultra tri-band filtering mitigates interference among 5 GHz and 6 GHz radios and prevents gaps in channel coverage.
• Since only Wi-Fi 6E enabled devices can operate in the 6 GHz band, it is less congested with no interference from legacy devices.

Extends capabilities of Wi-Fi 6 (802.11ax) APs

• HPE Aruba Networking 630 Series Campus Access Points are based on the 802.11ax standard so multi-user efficiency and security features are applied to Wi-Fi 6E.
• Unique HPE Aruba Networking capabilities include ClientMatch, Advanced Cellular Coexistence, and Intelligent Power Monitoring to optimize user experience and energy use.

Ensures Business Continuity and High Availability

• High availability with two HPE Smart Rate Ethernet ports for 1-2.5 Gbps to offer true hitless failover for both data and power.
• Cloud, controller, or controllerless operation modes address all campus, branch and remote use cases.

Specifications

TechnicalSpecifications
Ports	E0, E1: Two Ethernet wired network ports (RJ-45) Auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX 2.5Gbps speed complies with NBase-T and 802.3bz specifications POE-PD: 48Vdc (nominal) 802.3af/at/bt POE (class 3 or higher) 802.3az Energy Efficient Ethernet (EEE)
Mounting	A mounting bracket has been pre-installed on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately).
Connectivity, standard	Wi-Fi 6E (IEEE 802.11ax) WLAN: tri radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11ax 2x2 MIMO Bluetooth Low Energy (BLE5.0) and Zigbee (802.15.4) radio
Input voltage	12 Vdc (+/- 5%) or 48 Vdc (nominal) PoE
Power consumption	23.8 W worst case (POE powered), 20.7 W worst case (DC). Excludes power needed to supply up to 5W to an attached USB device.
Heat dissipation	66.3 BTU/hr worst case (PoE powered), 57.9 BTU/hr worst case (DC)
Certifications	UL2043 plenum rating Wi-Fi Alliance Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6GHz) WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, Wi-Fi Vantage, W-Fi Agile Multiband Wi-Fi Location Passpoint (release 2) Bluetooth SIG Ethernet Alliance (POE, PD device, class 5)
Regulatory	FCC/ISED CE Marked RED Directive 2014/53/EU EMC Directive 2014/30/EU Low Voltage Directive 2014/35/EU UL/IEC/EN 60950 IEC/EN 62368-1 EN 60601-1-1, EN60601-1-2
Wi-Fi antenna	Two integrated dual-band downtilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.6 dBi in 2.4 GHz, 7.0 dBi in 5 GHz and 6.3 dBi in 6 GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees. Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the combined, average pattern is 2.9 dBi in 2.4 GHz, 4.9 dBi in 5 GHz and 4.3 dBi in 6 GHz.
Radio coverage	Indoor, tri radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11ax 2x2 MIMO
Product dimensions (metric)	220mm (W) x 220mm (D) x 50mm (H)
Weight	1300g

Documents

HPE Aruba Networking 630 Series Campus Access Points QuickSpecs (English)

HPE Aruba Networking 630 Series Campus Access Points (English)
